Intense vibration at the handles of power tools can lead to long-term effects on blood vessels in the hands and arms. STIHL has therefore developed an effective anti-vibration system whereby the oscillations from the machine's engine are dampened which significantly reduces vibrations at the handles.
Catalytic Converter (D)
Considerably reduces the quantity of harmful particles in the exhaust gas.
Compensator
This controller in the carburettor prevents the fuel-air mixture getting richer as the air filter becomes clogged. The correct quantity of fuel is delivered to the carburettor depending on the quantity of air passing through the air filter. This keeps the fuel/air ratio in the combustion mixture constant and hence also the engine power. The filter doesn't need to be cleaned until an appreciable drop in power occurs.
Ematic chain lubrication system
The Ematic chain lubrication system ensures pinpoint lubrication of the saw chain links and guide bar rails. When used with STIHL OILOMATIC saw chain, it will provide maximum lubrication, longer wear and less oil consumption than conventional methods of chain lubrication. The Ematic system can reduce bar oil consumption by up to 50%.
Single-lever master control
All important functions such as start, choke, throttle and stop are operated via a single lever.
Additional Features
STIHL ElastoStart
STIHL ElastoStart reduces the shock caused by the compression of the engine during starting. The compression shock is taken away from the user's joints and muscles through a spring or rubber element in the starter handle.
Side chain tensioner
The tensioning screw can be found on the side of chain saw through the sprocket cover. This removes the need for contact with the sharp saw chain.
Displacement cm³
30.1
Power output kW/bhp
1.2/1.6
Weight kg 1)
4.1
System weight kg 2)
4.57
Power-to-weight ratio kg/kW
3.4
Sound pressure level dB(A) 3)
100
Sound power level dB(A) 3)
111
Vibration values left/right m/s² 4)
5.2/5.5
STIHL Oilomatic saw chain pitch/type
3/8" P PMM3
Oil pump
Not adjustable
Tank volume l
0.25
Chain pitch
3/8"P
Chain tensioning
Chain tension
Sprocket - number of teeth
6
Filter
Simple Filter plate
Bumper spike
Plastic spike
Cylinder
Chrome
Oil tank volume cm3
145
Sprocket
Sprocket profile
Anti vibration system
Standard AV-System
Filler cap
Standard
Starting system
Single lever / Standard starter handle
EPA Certified fuel consumption l/h
0.671
1) Without fuel, without bar and chain
2) Unfueled, with guide bar and saw chain
3) K-factor according to DIR 2006/42/EC = 2.5 dB (A)
4) K-factor according to DIR 2006/42/EC = 2m / s ²
