The loop handle provides freedom for movement and ease of operation, even under cramped conditions.
Anti-vibration system
Intense vibration at the handles of power tools can lead to long-term effects on blood vessels in the hands and arms. STIHL has therefore developed an effective anti-vibration system whereby the oscillations from the machine's engine are dampened which significantly reduces vibrations at the handles.
Shoulder Strap / Carrying System
Using a STIHL shoulder strap or carrying harness with soft padding makes work more comfortable, particularly during lengthy jobs.
Multi-function control handle
This houses all the engine controls. Easy, comfortable thumb-operated control means the operator's hand never leaves the handle.
Decompression system
The decompression system allows some of the compression pressure in the cylinder to escape, so less force on the starter rope is needed.
Manual fuel pump (purger)
A small fuel pump delivers fuel to the carburettor at the touch of a button. This reduces the number of starting pulls required following extended breaks in operations.
Performance kW
0.75
Performance bhp
1
Displacement cm³
21.4
Sound pressure level dB(A) 1)
91
Sound power level dB(A) 1)
106
Power output kW/bhp
0.75 / 1.0
Vibration level right m/s² 2)
4.5
Stroke rate 1/min
3.615
Vibration level left m/s² 2)
4.1
Tooth spacing mm
34
Weight kg 3)
6.0
Total length cm
232
Blade length cm
50
1) K-factor according to DIR 2006/42/EC = 2.5 dB (A)
2) (K) factor according to Dir. 2006/42/EC = 2m/s²
3) Without fuel, complete
