Compact chainsaw with excellent power-to-weight ratio. With up to 20% less fuel consumption and up to 70% fewer emissions compared to STIHL two-stroke engines of the same performance class without 2-MIX technology. Ideal for cutting firewood, felling small trees and when a bit more power is needed.
£447.99 – £455.00 Ex VAT
£537.59 – £546.00 Inc VAT
Compact chainsaw with excellent power-to-weight ratio. With up to 20% less fuel consumption and up to 70% fewer emissions compared to STIHL two-stroke engines of the same performance class without 2-MIX technology. Ideal for cutting firewood, felling small trees and when a bit more power is needed.
This saw is easy to guide and has great handling. With STIHL Quick Chain Tensioning and STIHL ErgoStart.
Intense vibration at the handles of power tools can lead to long-term effects on blood vessels in the hands and arms. STIHL has therefore developed an effective anti-vibration system whereby the oscillations from the machine’s engine are dampened which significantly reduces vibrations at the handles.
STIHL long-life air filtration systems with pre-separation achieve perceptibly longer filter life compared with conventional filter systems. Air drawn in is swirled. The larger, heavier particles are ejected. The pre-cleaned air is routed to the air filter via the pre-separator duct.
This controller in the carburettor prevents the fuel-air mixture getting richer as the air filter becomes clogged. The correct quantity of fuel is delivered to the carburettor depending on the quantity of air passing through the air filter. This keeps the fuel/air ratio in the combustion mixture constant and hence also the engine power. The filter doesn’t need to be cleaned until an appreciable drop in power occurs.
All important functions such as start, choke, throttle and stop are operated via a single lever.
A genuine advance in easy starting. STIHL ErgoStart (E) cuts the effort required to start the tool by half, while the starter cord can be pulled at just one third of the normal force. All it takes is 2 fingers and a gentle pull action.
After releasing the sprocket cover the chain can be adjusted using a thumb wheel without the need for tools.
Special catches on the fuel and oil tanks for easy opening and locking without the need for tools.
| Weight | 8 kg |
|---|---|
| Dimensions | 1 × 1 × 1 cm |
| Size | 35cm/14" Bar, 40cm/16" Bar |
| Brand | Stihl |
| Customer Type | Domestic / Homeowner |
| Power | Petrol |
| Technical data | Value |
|---|---|
| Displacement cm³ | 42.6 |
| Power output kW/bhp | 2/2.7 |
| Bar length cm | 35-40 |
| Bar length " | 14-16 |
| Weight kg 1) | 5.1 |
| Weight kg 2) | 5.78 / 5.88 |
| Power-to-weight ratio kg/kW | 2.6 |
| Sound pressure level dB(A) 3) | 103 |
| Sound power level dB(A) 3) | 114 |
| Vibration values left/right m/s² 4) | 3.9/3.9 |
| STIHL Oilomatic saw chain pitch/type | 3/8" P PM3 |
| STIHL Oilomatic saw chain pitch/type | 3/8" P |
| Oil pump | Not adjustable |
| Tank volume l | 0.39 |
| Chain pitch | 3/8" P |
| Chain tensioning | Chain Quick Tensioning,Side chain tension |
| Sprocket - number of teeth | 6.6 Z |
| Filter | Long-term filter system / round cartridge filter |
| Filter material | Flocked,Non-woven filter |
| Bumper spike | Steel claw |
| Cylinder | Chrome |
| Oil tank volume cm3 | 200 |
| Sprocket | Profile chain row,Sprocket profile |
| Anti vibration system | AV + steel spring |
| Filler cap | Tools,WTV tool-free tank cap |
| EPA Certified fuel consumption l/h | 1.06 |
| CO² g/kWh | 917 |
| Handle type | Standard grip,Standard handle |
| Exhaust | Standard muffler,Standard silencer |
| Carburettor | Compensator / Limiter Caps / scavenging / Carburetor,Flushing template / carburetor preheating / compensator / limiter caps |
| Speed at maximum power rpm | 10.000 |
| EPA Certified fuel consumption glh | 0.28 |
1) Without fuel, without bar and chain
2) Without fuel, with bar and chain
3) K-factor according to DIR 2006/42/EC = 2.5 dB (A)
4) K-factor according to DIR 2006/42/EC = 2m / s ²
The version(s) available in each country may differ from the above range and specifications; specific details may be subject to change without notice. Please ask your local STIHL Approved Dealer for further information.
